Milk tankers are suitable for dedicated line transportation and cross-border distribution in dairy factories.
Your trusted fresh milk transportation solution
Applications
This milk tank truck is mainly suitable for scenarios such as transportation from large pastures to dairy processing plants, raw material allocation within dairy enterprises, long-distance cross-provincial fresh milk transportation, centralized milk collection and distribution from multiple pastures, liquid food transportation, and cold chain logistics transportation.
Why choose our 13 ton milk tank truck?
- Food-grade Safety: The inner tank is made of 304/316L food-grade stainless steel with mirror polishing that leaves no dead corners. The welding process complies with dairy hygiene standards, does not contaminate milk sources, and fully meets the acceptance requirements of pastures and dairy enterprises.
- Independent Compartments for Multi-purpose Use: Featuring an independent compartment design, it can transport fresh milk from different pastures and different batches simultaneously without mixing or cross-contamination. Loading and unloading are flexible, allowing one trip to accomplish the work of multiple trips.
- Industry-leading Insulation Performance: The tank adopts a three-layer structure plus high-density polyurethane integral foaming, with a thick and uniform insulation layer. The temperature difference within 24 hours is ≤1℃, ensuring fresh milk remains unspoiled and at a stable temperature even during long-distance transportation and in high-temperature weather.
- Automatic Cleaning: Each compartment is equipped with a 360° rotating cleaning ball. Automatic flushing and disinfection can be realized by connecting an external water source without manual entry into the tank, saving time and labor while meeting hygiene standards.
- Exquisite Workmanship: The tank is corrosion-resistant and impact-resistant, with built-in anti-slosh plates for more stable driving.
Comprehensive Safety Protection
- Tank Structure Safety: The tank adopts a three-layer reinforced structure with a thickened stainless steel inner liner, featuring impact resistance and deformation resistance. It is equipped with a pressure breather valve to automatically balance the air pressure inside and outside the tank, an anti-overflow alarm device, and an automatic full-load reminder.
- Operation Safety: Pneumatic discharge valve plus emergency cut-off device enable convenient milk loading and unloading operations with remote emergency stop function, eliminating misoperation.
- Hydraulic System: The tank hydraulic system is equipped with a safety lock to prevent accidental falling during lifting and maintenance, ensuring maintenance safety.
Technical Specifications
|
product name
|
milk tanker
|
overall dimensions of a car
|
10800 × 2500 × 3150 mm
|
|
Maximum capacity
|
13000L
|
Tank dimensions
|
6800×2400×1800mm
|
|
rated load mass
|
14805kg
|
curb weight
|
10205kg
|
|
Subwarehouse
|
3 warehouses evenly distributed/through warehouse
|
Tank form
|
Oval horizontal design with integrated tank and vehicle
|
|
Tank material
|
SUS304-2B food-grade
|
Inner liner thickness
|
δ3.0 mm
|
|
Outsource thickness
|
δ1.5mm
|
Milk duct diameter
|
∮51mm National Standard/Non-standard
|
|
heat insulating material
|
80 mm polyurethane spray coating
+10mm rubber-plastic insulation cotton
|
heat-insulating property
|
The polyurethane foam coating is applied for insulation performance, with a maximum temperature rise of 2°C within 24 hours.
|
|
Tank head
|
Perfect circle
Thickness 3.5 mm
|
Cleaning method
|
CIP automatic cleaning system, with cleaning balls installed in each chamber to meet 360° cleaning requirements
|
|
automobile chassis
|
Fuhua 3-axle 10-ton drum axle with 16-ton brake pads, 1-3 axle systems featuring ABS and automatic adjustment arms, equipped with 12 sets of 12R22.5 vacuum tires, steel wheels [aluminum alloy wheels optional with an additional 6,000 yuan], aluminum alloy support legs, side guards, fenders, and rear protection.
|
|
Video
Drawing
Main Components
-
Tank insulation layer
The entire tank truck is covered using imported polyurethane spray foaming technology, which is fireproof and moisture-proof.
-
Outer shell protective layer
The outer covering plate of the tank covers the entire exterior of the tank using a 1mm stainless steel plate overlapping and welding-free process.
-
Food Processing
Made of SUS304-2B food-grade stainless steel, it is evenly distributed inside the tank body, and the cleaning spray water can rotate 360° to achieve all-angle cleaning without blind spots.
-
Tank frame keel
The tank body adopts a keel frame and stiffener design, which provides effective support for the inner tank of the tank and improves the bearing capacity of the inner tank.
-
-
Inner head
It is welded to the inside of the tank liner using stainless steel plates by means of argon arc welding with full penetration welding
Reliable Warranty & Global Support
- 12-Month Warranty: Full vehicle coverage (excluding wear parts) for your peace of mind.
- Instant Technical Support: 24/7 technical feedback with immediate solutions for any fault.
- Free Operator Training: On-site or remote training on hydraulics, safety, and operation.
- Global parts supply: Fast delivery of milk tanker truck and hydraulic parts to minimize equipment downtime.
- Multi-Brand Support: Professional diagnostic guidance even for your existing fleet of other brands.
Frequently Asked Questions
Q: What is the lead time for customizing a 13-ton milk tank truck?
A: Standard configurations are usually ready in 20–30 days. Custom painting or specific emission requirements may take up to 40 days.
Q: Does this milk tank truck come with certification documents that meet international standards?
A: Yes, this milk tank truck will be delivered with a complete set of internationally recognized certification documents in accordance with the standards of the destination country, including COC, food-grade material test reports, hygiene certificates, and safety performance certificates, which fully meet local customs clearance and regulatory requirements.
Q: What are your shipping conditions?
A:Normally,we transport trucks via roll-on/roll-off ships, bulk carriers, and containers. Spare parts are packed in wooden cases and transported by container.
Q: Can you fully customize according to my requirements?
A: Yes. We have a professional R&D team and can accurately produce products according to your requirements.
